Payment & Shipping Terms:
|Car Model:||Benz GL/GLS||Year:||2013|
|Material:||Non-slip Rubber，C45||Max Load:||About 200kg|
|Type:||Auto||Test Time:||More Than 40000|
auto retracting running boards,
electric retractable running boards,
Anti Collision Auto Retracting Running Boards
Anti Collision Auto Retracting Running Boards , Power Side Steps Benz GL / GLS 2013
Power Step Running Board Introduction
Since the United States AMP Company developed the four-bar Power Step Running Board for off-road vehicles in 2010, in the past seven years, the number of electric treadmill models has been increasing year by year, but the electric Power Step Running Board of the vehicle is still continuing the four-link structure of AMP. The structural thinking of electric Power Step Running Board inside and outside the industry has also tended to solidify, and the four-link bracket has become the synonym of electric Power Step Running Board.
Is "Leadism" suitable for Urban SUV?
It is well known that pick-up truck is the most common type in foreign countries, which belongs to both passenger and cargo models. The height of chassis is 400mm from the ground. The design intention of four-bar Power Setp Running Board is only to meet the high chassis pick-up truck, large off-road vehicle type.
However, It is worth pondering that domestic SUV models in the chassis in the 150-200mm city of SUV, accounting for 70-80% of the domestic SUV. Blind use of the same four-bar-rod bracket, obviously did not take the initiative to carry out specific problems specific analysis. If these models are not fitted with four-bar electric treads, the limit of the human body's upper steps is 165mm, which makes it difficult to get on and get on, especially for the elderly and children. If the four-bar electric treads are installed, the panels are close to the ground and the height cannot be adjusted. Inconvenient use often leads to expensive smart electric treadmill only to play a decorative role.
Swing arm power Step Running Board came into being
The aspirations of SUV owners in many cities show that the traditional four-bar electric Power Step Running Board has reached the point where it has to be innovated. The emergence of new things is also under the pressure of demand. Wharton's mission, which lasted 13 months, finally launched the electric Power Step Running Board with swinging arm structure in this environment.
Advantage for Swing arm power Step Running Board
|1.Height||According to the distance from the threshold to the ground and the most comfortable step height of the human body, the height of the pendulum arm is set at an equal distance from the ground height.|
|2.Width||In contrast, the pendulum arm has already occupied the innate advantage in the structure design, the pendulum arm can make the panel hidden in the bottom part of the vehicle completely protrude out, the extension width exceeds 128mm, the stampede area can be increased, and the ladder advantage can be maximized.|
The bracket is perfectly stored in the side skirt of the car, without reducing the chassis and reducing the risk of impact;The gap between the panel and the body is less than 10mm, which protects the body from external sand and gravel; Whole body is made of precision cast iron Q235, hard, firm and safe.
The torque distribution is optimized, the movement path is shortened, and the motor runs more quietly, well below 40 decibels, thus prolonging the service life of the motor.
The support is hidden in the grooves of the chassis of the body, the panel and the side skirt are closely dressed, which does not affect the exterior design of the vehicle, and meets the requirements of the car owners who require a higher appearance.
New key unlocking Power Step Running Board function, through the key remote control Power Step Running Board, unlocking one side Power Step Running Board out stretched, unlock twice Power Step Running Board out stretched, latch key can be put off the Power Step Running Board.
When the OBD system receives the car lock order, the Power Step Running Board will be automatically put up, and the safety performance will be increased.
With Power Step Running Board protection, the Power Step Running Board will automatically close when the car starts at 5km/h speed.
