Automatic Car Trunk Electric Tailgate Lift Kit For Toyota Alphard Vellfire 10 With Remote Control

China Dongguan Kaimiao Electronic Technology Co., Ltd certification
China Dongguan Kaimiao Electronic Technology Co., Ltd certification
Hello, Florence. We have tested one tailgate on Hyundai Tucson. We found that the product quality is good

—— Bolkar

they products are the best in the market we have used other company. there back up service is professiona.l

—— Mr. Nolan

I'm Online Chat Now

Automatic Car Trunk Electric Tailgate Lift Kit For Toyota Alphard Vellfire 10 With Remote Control

Automatic Car Trunk Electric Tailgate Lift Kit For Toyota Alphard Vellfire 10 With Remote Control
Automatic Car Trunk Electric Tailgate Lift Kit For Toyota Alphard Vellfire 10 With Remote Control
video play

Large Image :  Automatic Car Trunk Electric Tailgate Lift Kit For Toyota Alphard Vellfire 10 With Remote Control

Product Details:
Place of Origin: China
Brand Name: KaiMiao
Certification: Rohs, E-marks E24
Model Number: KMDS231 / KMDH231
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: 1 pc: US$230, ≥2 pcs: Negotiable
Packaging Details: 80*23*15cm,5.5-6 kg
Delivery Time: 3-5 working days
Payment Terms: T/T, PayPal, Western Union
Supply Ability: 2000 sets per month
Detailed Product Description
Application: Toyota Alphard Vellfire 10 Year: 2002-2008
Function: Remote Control, Set The Height, Automatic And So On Material: Metal And Plastic
Type: Upgrade Car Trunk Rated Voltage:: 12V
Operating Voltage:: 9-16V Working Current:: 5A
Quiescent Currenty:: <2mA Operating Temperature:: -30℃~80℃
High Light:

Remote Control Electric Tailgate Lift Kit


Toyota Alphard Electric Tailgate Lift Kit

Automatic Car Trunk Electric Tailgate Lift Kit For Toyota Alphard Vellfire 10 With Remote Control


What is electric tail gate lift system?

Electric tailgate lift assisting system opens and closes your tailgate by simply pressing a button. This smart aftermarket lift gate provides additional security and value to your vehicle. Installation is designed for the do-it-yourself and comes with various brackets depending on your car.


Electrical hookup has never been easier, with a easy to install switch and a Plug and Play Harness. This reliable system will perform a hydraulic system without all the complicated plumbing and upkeep. The kit includes Control Module, Plug and Play Harness along with mounting brackets and hardware plus easy to understand instructions


When standing with the proximity smart key for more than three seconds within a metre of the rear of the vehicle, the Smart foot senses your presence and automatically opens to allow you to store your cargo, hands free. The Smart foot also opens and closes at the press of a button from the driver's seat or outside of the car.


Product Features:

1.Control by the remote, one press fix all

Press on the remote control to open/close the tail gate, even if your hands are busy, you do this easily.

2.Button on tail gate, great hand control

A light touch on the button on tail gate, it close as you require.

3.Button in driver's seat, control easily

When you are in driver's seat, press the button to control tail gate easily.

4.Smart avoid pinch, user-safely

While the tail gate is closing , one it touch the obstacles, it will bounce back automatically or stop here, so avoiding hurt you

5.Set the height, user-friendly

The tail gate can memory the height, user pull the gate to a level you could reach, then long press on the button so the height is settled. Next time, you open it, it stay the height you set. So you never afraid that it will be too high for you to reach.

6.Sound alarm, warning timely

When close or open the tail gate, it will send out sound to alarm the driver and knowing the back situation to avoid damage or security risks.



Installation Precautions of Electric Tail gate Lifters

  • 1. To ensure safety and normal usage of our products, please let the professional staff to stall; To avoid damaging the machine or causing accidents, please do not dismantle the products.
  • 2.To start the engine before installation, check the car dashboard display function, whether the buttons operate normally, whether there is any scratches on car interior and surface.
  • 3.Check whether the tailgate can normally open or close or not, check if there is any problem with the lights.
  • 4.Turn off the engine, preparing tools.
  • 5.For installation personnel: Please remove metal objects and any other hard objects to prevent car damage during the installation process.
  • 6.Remove automotive components and place them carefully to avoid scratching the dashboard; wiring debris need to be tidied up in time, do not leave them in the car; Joints must be well insulated to prevent short circuits.
  • 7.According to our wiring way, to avoid affect the car moving parts, such as steering column, the accelerator and brake pedals, etc., each harness should fixed after wiring , to avoid getting loose.
  • 8.Connect each harness according to our wiring way (pay attention to the position of ground wire)
  • 9.Do not change the wires or accessories with the power on.

Automatic Car Trunk Electric Tailgate Lift Kit For Toyota Alphard Vellfire 10 With Remote Control 0

Laboratory Test:

Test Description
Water-Proof Test Perform IPX4 waterproof rating standard, put the poles in the car, dripping for 10 minutes, flusing for many times.
Salt Spray Test Place the poles in 5% NACL solution of salt spray for 256 hours, wash the solution with flowing water, rinse with distilled water, stand it for 1-2 hours. Finally check if the pole is rusty.
High Temperature Test Double pole load balancing. When a pole fails, the door can be prevented from being deformed. When the tailgate fails in a special scene, the system will automatically adjust the closing effort.
Low Temperature Test When the drive circuit is faulty( low-voltage alarm, over-current protection), it will automatically cut off / automatically recover to ensure the safety of vehicles and equipment.
High and Low Temperature Ultra-low quiescent current(Standby Current:1 mA). It can avoid that the vehicle can not start without power due to long-term parking.


Question & Answer:

Q: Could you print our logo on the package?

A: Sure. Generally, our package is uniform. If the customer has demands, we can customize according to customer's demands.

Q: How are you packing?

A: 1 set into 1 inner box and 2 or 4 sets in 1 carton box;

Q: How long to delivery?

A. If in stock, it will ship out after 7-10 days; If out of stock, it will take about 10-15 days.


Package & Shipping

Package Size: 80*23*15 cm
Gross Weight: ≈5.5-6 kg
Package Type: Neutral Packing
Delivery time: In stock: 1-2 working days
Out of stock: 5-7 working days
